Wilwood Master Cylinder

Wilwood Master Cylinder Specifications

This lightweight aluminium master cylinder is most often used for hydraulic handbrake installs. It can also be used with pedal boxes.

Which Master Cylinder to Choose ?

The ideal diameter of a master cylinder is often the subject of much debate, while the answer is very simple: there is no ideal diameter! Every driver and every vehicle is different. Without going into great theoretical explanations, remember that the larger the diameter of the master cylinder, the more liquid it moves when you pull it: the stroke of the lever will therefore be shorter and firmer, the effort to be provided by your arm will be higher. It can be difficult to properly dose braking in these conditions. On the contrary, with a small diameter master cylinder, the stroke will be longer, the lever easier to pull, and more dosable.

Generally speaking, a diameter between 15.8 mm and 19.1 mm is a good compromise for all uses. Otherwise, do not hesitate to contact our technical staff for more precise information, especially if you are using large multi-piston calipers. Several master cylinders are available, offering many variations in diameter, with or without brake fluid reservoir for separate calipers dedicated to the handbrake.

Technical information

Stem thread : 5/16" UNF
Input thread : 7/16" UNF
Output thread : 3/8" UNF

Various diameters available, select above!

12,70 mm - 1/2"
15,80 mm - 5/8"
17,80 mm - 7/10"
19,05 mm - 3/4"
20,60 mm - 13/16"

Customer Reviews 9 customer reviews

4.8

78% (7)
22% (2)

Product ordered on 19/04/2023 by Fabio S.

Bien
Product ordered on 27/05/2022 by Alexandre L.

Produit impeccable
Product ordered on 24/05/2022 by Adil t.

super pour debuter
Product ordered on 18/01/2020 by Florian E.

Very good
Product ordered on 29/12/2019 by Eliot C.

Very qualitative
Product ordered on 23/09/2018 by DAMIEN F.

Wilwood Quality
Product ordered on 10/04/2018 by Chihab J.

The essential FAM for any drifter who likes to practice his discipline in the most favorable conditions. Quality and finishing are at the rendezvous without mentioning the competitive price. Best quality-price ratio on the market
Product ordered on 20/11/2023 by Anthony D.

Conforme mais la nouvelle version semble differente de l'ancienne . Pour l'instant ca fonctionne . A voir dans le temps si les coupelles se font encore ronger par le liquide de frein competition ...
Product ordered on 04/11/2018 by Antoine G.

Good quality and efficiency
