HP Ignition AutoDiag Uprated Coilpack for Audi R8, Porsche, VAG
High Performance Ignition
- Self-diagnosis uprated coilpack
- To suit : VAG & Porsche (see application list below)
- Solve misfires and hesitant performance
- High quality and reliability
- Provide a power and torque gain up to 4%
- Popular and universal fitment to many tuned engines
- Simplify and speed up interventions on competition vehicles
- Equivalent to OEM part number : 06E905115A , 06E905115B, 06E905115C, 06E905115D, 06E905115E
- Sold individually
Ask a question about this productApplication List
- Audi A3 8P 2.0L TFSI (04-12)
- Audi A4 B8 2.0L TFSI (07-15)
- Audi A5 8T 2.0L TFSI (07-15)
- Audi R8 4.2L V8 FSI (06-10)
- Audi R8 4.2L V8 FSI (08-15)
- Audi RS3 2.5L TFSI (11-17)
- Audi RS4 B7 4.2L V8 FSI (06-08)
- Audi RS4 B8 4.2L V8 FSI (12-15)
- Audi RS5 B8 4.2L V8 FSI (10-16)
- Audi S3 8L (96-03)
- Audi S3 8P (06-12)
- Audi S4 3.0L V6 (10-15)
- Audi S4 B7 4.2L V8 FSI (05-08)
- Audi S5 3.0L V6 (10-15)
- Audi S5 B7 4.2L V8 FSI (07-11)
- Audi TT & TTS 8J 2.0L TFSI (06-13)
- Audi TT 8N (96-06)
- Audi TTRS 2.5L TFSI (09-14)
- Porsche Cayenne 3.0L V6 (02-10)
- Porsche Cayenne 3.0L V6 (10-17)
- Porsche Panamera 3.0L V6 (09-16)
- Seat Leon 1M 1.8T (99-06)
- Seat Leon 1M Cupra (99-06)
- Seat Leon 1P 2.0L TSI & TFSI (05-12)
- Seat Leon 1P Cupra (05-12)
- Volkswagen Golf 4 GTI (98-04)
- Volkswagen Golf 5 GTI (04-09)
- Volkswagen Golf 6 GTI (09-12)
- Volkswagen Golf 6 R (09-12)
- Volkswagen Polo 6R WRC (09-14)
- Volkswagen Polo 9N GTI (05-09)
- Volkswagen Scirocco 2.0L TSI & TFSI (08-17)
- Volkswagen Scirocco R (08-17)
- Volkswagen Touareg 3.0L V6 (10-17)
- Volkswagen Touareg 4.2L V8 (02-10)
- Volkswagen Touareg 4.2L V8 (10-17)
(non-exhaustive listing)
Self-Diagnosis ?
Designed for racing, the HP Ignition AutoDiag coilpacks are equipped with an additional component visible on the top, monitoring the ignition. This permanent monitoring is performed according to well-defined criteria, such as the secondary discharge time. When a cylinder encounters ignition issues, a red LED is activated on the corresponding coilpack in order to help troubleshooting (defective spark plug, for example).
When starting the engine, all the coilpacks activate their LEDs for 5 seconds then switch off simultaneously, confirming the correct operation of the AutoDiag feature. If a coilpack's LED remains on (or comes back on later), it means that the corresponding cylinder is having an ignition issue. HP Ignition AutoDiag coilpacks are ideal for competition where they facilitate technical interventions and maintenance, and speed up troubleshooting in the paddocks.
HP Ignition Uprated Coilpacks Specifications
Specially designed for tuned engines, operating at high revs and temperatures, the HP Ignition coilpacks offer superior resistance and quality compared to OEM ignition coils. The installation of HP Ignition coilpacks will solve all common ignition problems, such as misfires and hesitant performance.
The HP Ignition coilpacks provide a gain in horsepower and torque up to 4 % thanks to their high and stable voltage, ensuring a powerful spark even at high revs. The installation is totally "plug & play", without any modifications or adjustments necessary.
Comparative Performance Graph
Comparison carried out by our partner W-Autosport, using a bone stock Nissan 200SX S14 with an SR20DET engine.
Characteristics
| Car Make | Audi, Peugeot, Seat, Skoda, Volkswagen |
|---|---|
| Engine Code | V8 FSI |
| Manufacturer | HP Ignition |
| Manufacturer SKU | 06E905115A |
Specially designed for tuned engines, operating at high revs and temperatures, the HP Ignition coilpacks offer superior resistance and quality compared to OEM ignition coils. The installation of HP Ignition coilpacks will solve all common ignition problems, such as misfires and hesitant performance. The HP Ignition coilpacks provide a gain in horsepower and torque up to 4 % thanks to their high and stable voltage, ensuring a powerful spark even at high revs. The installation is totally "plug & play", without any modifications or adjustments necessary.
