Deatschwerks DW430C 430 L/h E85 Fuel Pump, Universal Install Kit with Clips

Deatschwerks DW430C 430 L/h E85 Fuel Pump

When modifying or rebuilding and engine, or for a simple FlexFuel conversion, the stock fuel pump is often insufficient and can't let fuel flow through quick enough. The consequences can be disastrous, in the worst case a broken engine (a lean air/fuel mix causing knocking).

The Deatschwerks DW430C (C for Compact) can fit in many modern brackets, in which a standard size pump won't. It is capable of delivering 430 lph at 2.7 bar pressure. It has a quiet impeller and is specifically designed for ethanol (E85). It is the only pump on the market with a 3 year warrantee.

Please note that a high flow fuel pump won't increase your vehicle's power. It allows you to replace your existing pump that may be worn or insufficient, and can withstand an increased fuel flow for engine upgrades with high boost pressure, bigger injectors, or other modifications.

Technical Specifications

• Components of the universal kit : see picture(s)
• Input diameter : 8 mm internal, 11 mm external
• Output diameter : 8 mm
• Voltage : 12 V
• Maximum pressure : 7 bars
• Maximum flow : 503 liters / hour
• Flow at 3 bars : 469 liters / hour
• Flow at 5 bars : 357 liters / hour
• Length : 111.40 mm
• Diameter : 38 mm
• Weight : 290 grams
• Need more technical data ? Check out the installation guides on Deatschwerks official website

DriftShop supplies these pumps straight from the manufacturer. These Deatschwerks pumps are 100% authentic with a 3 year manufacturer warrantee.
