AEM Stainless Steel MAP Sensor - 7 bar
Dispatched Thursday, April 25, 2024
AEM MAP 7 bar Sensor
- Air pressure sensor (up to 7 bars)
- Ideal for an AEM ECU
- Material: high quality stainless steel
- Ultra-precise and quick readings
- Signal output : 0.5 to 4.5V linear
- Operating temperature range: -40 to + 105° C
- Thread : 1/8" NPT
- Supplied with two adapters for easy installation (Dash 4 and barb for 5 mm hose)
- AEM part no. : 30-2130-7
Ask a question about this productAEM MAP 7 bar Sensor Kit Specifications
This MAP (Manifold Absolute Pressure) sensor can support an absolute pressure of 7 bars, equivalent to a boost pressure of 6 bars. It allows to measure the air pressure in the intake manifold, and transmit this info to the ECU, which will calculate the corresponding amount of fuel to inject.
This ultra-precise sensor is particularly recommended for joint use with AEM ECUs. It is made of high quality stainless steel and has a 1/8" NPT thread (4 and 5 mm Dash adapters supplied, see photo).
Technical Specifications
- Accuracy : +/- 0.5% from 0 to 7 bars
- Minimum / maximum operating temperature : -40° C to + 105° C
- Response time <1 ms
- Material : 304L and 316L stainless steel
- Sampling : 100 to 2000 Hz, 20g sinusoidal, 3 axes
- Weight : 85 g
- Electric power consumed <30 mW
- Output voltage : 0.5 to 4.5V linear
- High Quality waterproof connector
Characteristics
| Manufacturer | AEM |
|---|---|
| Manufacturer SKU | AEM-30-2130-7 | 9026.20.4000 |
Behind the first "plug & play", programmable ECU in the 90's, the American company AEM is reknown for its high performance electronical parts. From adjustable ECUs to all sorts of gauges, wideband kits, water and methanol injection kits, dataloggers and fuel pumps, AEM offer the best solutions for the most highly tuned vehicles.
