ACL Race Series Reinforced Rod Bearings - Holden V8 253 4.2L, 308 5.0L

ACL

* generic picture

Some options are available below Please check them before adding to the cart

ACL Race Series Rod Bearings

ACL trimetal rod bearings
To suit high RPM/load applications
Offer reduced friction and operating temperatures
Increased oil supply and overall lubrication
To fit : Holden V8 253 4.2L, 308 5.0L - full application list below
Made in Australia

Ask a question about this product

Your choice *Please fill in this field.
1 x ACL Race Series Bearings - Standard Size (P/N 8B2356H-STD) +€127.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - Repair Size 0.001" (0.025 mm) (P/N 8B2356H-001) +€127.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - Repair Size 0.010" (0.25 mm) (P/N 8B2356H-010) +€127.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - Repair Size 0.020" (0.50 mm) (P/N 8B2356H-020) +€127.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - HX Size (P/N 8B2356HX-STD) +€127.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - Standard Size & CT-1 Coating (P/N 8B2356HC-STD) +€175.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - Repair Size 0.010" (0.25 mm) & CT-1 Coating (P/N 8B2356HC-010) +€175.99 (Dispatched under 5 to 7 days)
1 x ACL Race Series Bearings - HX Size & CT-1 Coating (P/N 8B2356HXC-STD) +€175.99 (Dispatched under 5 to 7 days)

€0.00

Engineering Bulletin

ACL provides an official guide for clearance control and optimization, and guidelines for bearing size selection : download it here.

ACL Race Series Reinforced Rod Bearings

Designed to withstand high RPM, temperatures and load, these ACL Race Series bearings are manufactured from 3 layers of hardened steel, copper and nickel. This "trimetal" composition substantially lowers friction, and thus reduces the operating temperatures while providing superior lubrication.

To help engine builders optimise clearances for their specific applications, ACL provides a range of different bearing sizes for standard crankshaft journal sizes:

H-STD: Bearing thickness is precision finished to provide a nominal clearance based on OEM specifications. Suitable for all applications using crankshafts finished to OEM specifications.
HX-STD: Providing an extra .001" (0.025mm) of clearance over the H-STD size bearings. Suitable for high to extreme power applications where additional clearance is beneficial to part reliability.
H-001 / H-.025: Providing a reduction of .001" (0.025mm) of clearance over the H-STD size bearings. Suitable for adjusting clearance to compensate for surface reconditioning (polishing) of crankshaft journals or the use of low viscosity lubricants.

Please note: there are also HD (with location dowel holes) and HXD (with location dowel holes and 0.025mm (0.001") extra clearance) part numbers, reserved for some connecting rod bearing applications only.

Application List & Engine Codes

Holden/Commodore VB, Kingswood, Monaro, Premier HG, HJ, HQ, HT, HX, HZ, Statesman HQ, Torana LH, LX/OHV 16v/253 Red Motor
Holden/Commodore VC, VH, Ute WB/OHV 16v/253 Blue Motor
Holden/Commodore VB, Kingswood, Monaro, Premier HG, HJ, HQ, HT, HX, HZ, Statesman HJ, HQ, HX, HZ, Torana, LH, LX/OHV 16v/308 Red Motor
Holden/Commodore VC, VH, VK, Statesman WB, WBII/OHV 16v/308 Blue Motor
Holden/Commodore VL/OHV 16v/5.0L
Holden/Commodore VL/OHV 16v EFI/5.0L EFI
Holden/Commodore VN/OHV 16v EFI/5.0L EFI
Holden/Commodore VP/OHV 16v EFI/5.0L EFI
Holden/Commodore VR/OHV 16v EFI/5.0L EFI
Holden/Commodore VS/OHV 16v EFI/5.0L EFI
Holden/Commodore VT/OHV 16v EFI/5.0L EFI
Holden/Caprice VQ/OHV 16v EFI/5.0L EFI
Holden/Caprice VQII/OHV 16v EFI/5.0L EFI
Holden/Caprice VR/OHV 16v EFI/5.0L EFI
Holden/Caprice VS/OHV 16v EFI/5.0L EFI
Holden/Caprice Ute VG/OHV 16v EFI/5.0L EFI
Holden/Caprice VP/OHV 16v EFI/5.0L EFI
Holden/HSV Clubsport VN/OHV 16v EFI/5.0L EFI
Holden/HSV Clubsport VP/OHV 16v EFI/5.0L EFI
Holden/HSV Clubsport VR/OHV 16v EFI/5.0L EFI
Holden/HSV Clubsport VS/OHV 16v EFI/5.0L EFI
Holden/HSV Clubsport VT/OHV 16v EFI/5.0L EFI
Holden/Senator VP/OHV 16v EFI/5.0L EFI
Holden/Senator VR/OHV 16v EFI/5.0L EFI
Holden/Senator VT/OHV 16v EFI/5.0L EFI
Holden/Maloo/OHV 16v EFI/5.0L EFI
Holden/Manta/OHV 16v EFI/5.0L EFI
Holden/XU8/OHV 16v EFI/5.0L EFI
Holden/Statesman VQ/OHV 16v EFI/5.0L EFI
Holden/Statesman VQII/OHV 16v EFI/5.0L EFI
Holden/Statesman VR/OHV 16v EFI/5.0L EFI
Holden/Statesman VS/OHV 16v EFI/5.0L EFI
Holden/Statesman Ute VG/OHV 16v EFI/5.0L EFI
Holden/Statesman VP/OHV 16v EFI/5.0L EFI
Holden/HSV Caprice VR/OHV 16v EFI/5.7L Stroker
Holden/HSV Caprice VS/OHV 16v EFI/5.7L Stroker
Holden/HSV Caprice GTS VR/OHV 16v EFI/5.7L Stroker
Holden/HSV Caprice VT/OHV 16v EFI/5.7L Stroker
Holden/Senator VS, Grange VSII/OHV 16v EFI/5.7L Stroker
Holden/Grange VSII/OHV 16v EFI/5.7L Stroker
Holden/HSV Statesman VR/OHV 16v EFI/5.7L Stroker
Holden/HSV Statesman VS/OHV 16v EFI/5.7L Stroker
Holden/HSV Statesman GTS VR/OHV 16v EFI/5.7L Stroker
Holden/HSV Statesman VT/OHV 16v EFI/5.7L Stroker

Characteristics

Car Make	Holden
Bearing Type	Rod Bearings
Engine Code	Holden V8 Iron Lion

Designed to withstand high RPM, temperatures and load, these high strength bearings are manufactured by ACL from 3 layers of hardened steel, copper and nickel. This "trimetal" composition substantially lowers friction, and thus reduces the operating temperatures while providing superior lubrication.
